20
tira56e1 (2010-02) PxG55x.cp
Standard Telegrams (concluded)
Standard
telegram
Master
⇔
Slave
Bytes Meaning
204 S ⇒ M
0…7
8
9…12
13
14…15
Parameter Channel
Exception Status
Process Value float
OneOfN Status Extension
Trip Relay 1-2
205 1) S ⇒ M
1
2
Status (Bit 4…7) 2) and
Measurement Value 2)
Measurement Value 2)
206 1) M ⇒ S 1…2
Two bytes are sent to the slave but are not
processed by the slave
1) Available in TTR compatibility mode only.
2) Bit 7: 0 = no error / 1 = error
Bit 6: 0 = Trip Point 1 not activated / 1 = Trip Point 1 activated
Bit 5: 0
Bit 4: 0
The measurement value is given as a 12-bit value. Byte 1 / Bit 3 represents the MSB,
Byte 2 / Bit 0 the LSB
p [mbar] = 10
Measurement_Value / 482 - 4.778
p [Torr] = 10 Measurement_Value / 482 - 4.9029
p [Pa] = 10 Measurement_Value / 482 - 2.778
The devices support the following standard telegrams:
Standard
telegram
M ⇒ S
Standard
telegram
S ⇒ M
Configuration data
- 1 0x42,0x82,0x05,0x03
- 2 0x42,0x84,0x05,0x08
- 3 0x44,0x84,0x05,0x05, 0x05, 0x03
- 4 0x44,0x86,0x05,0x05, 0x05, 0x08
2 7 0xC4,0x87,0x8A,0x0A,0x0A,0x05,0x03
2 8 0xC4,0x87,0x8C,0x0A,0x0A,0x05,0x08
2 9 0xC6,0x87,0x8C,0x0A,0x0A,0x05,0x05, 0x05, 0x03
2 10 0xC6,0x87,0x8E,0x0A,0x0A,0x05,0x05, 0x05, 0x08
- 201 0x44,0x85,0x05,0x03,0x05,0x0A
- 202 0x44,0x87,0x05,0x08,0x05,0x0A
2 203 0xC6,0x87,0x8D,0x0A,0x0A,0x05,0x03,0x05,0x0A
2 204 0xC6,0x87,0x8F,0x0A,0x0A,0x05,0x08,0x05,0x0A
206 205 0xA1,0x91
4.4.2 Configuration Data
