8 Sensor Analog Input Function Blocks
All gauge functions of the PxG55x are described in the Analog Input Function
Block. Depending on the device configuration there are up to 3 measuring systems
included.
Because the gauge includes three measuring systems, there are three Analog
Input Function Block Instances:
• Instance 1 represents the Capacitance Diaphragm Gauge (CDG) measuring
part of the gauge ( → 34).
• Instance 2 represents the Pirani measuring part of the gauge (→ 37).
• Instance 3 represents the Atmosphere Pressure Sensor (ATM) measuring part
of the gauge ( → 40).
Because the gauge includes only one measuring system, there is only one Analog
Input Function Block Instance:
• Instance 1 represents the Pirani measuring part of the gauge (→ 37).
This function block describes the functionality of the Capacitance Diaphragm
Gauge (CDG) measuring part of the gauge.
The PSG55x does not have a Capacitance Diaphragm Gauge (CDG)
and this function block (CDG) is not supported.
The following attributes are supported:
ID Name Structure Data type Bytes Access Store →
15 AIBlockAdjust Command Record UINT8 2 1_R/W
2_R/W
N 35
16 Block Type ID Simple OSTRING(n
) 4 1_R
2_R
N 35
19 ProcessValue (PV) Simple *) – 0_XI
1_R
2_R
D 35
20 Status Simple UINT8 1 0_XI
1_R
2_R
D 35
21 Data Type Simple UINT8 1 2_R/W N 35
22 Data Unit Simple UINT16 2 2_R/W N 36
23 Reading Valid Simple Boolean 1 1_R
2_R
D 36
24 Full Scale Simple *) – 1_R
2_R
N 36
39 Safe State Simple UINT8 1 1_R/W
2_R/W
N 36
40 Safe Value Simple *) – 1_R/W
2_R/W
N 36
41 Auto Zero Enable Simple Boolean 1 1_R/W
2_R/W N 36
44 Overrange Simple *) – 1_R
2_R
N 36
45 Underrange Simple *) – 1_R
2_R
N 36
*) According to data type value (ID 21)
