12
tira56e1 (2010-02) PxG55x.cp
Depending on the standard telegrams used ( → section "Cyclic Message Tele-
grams"), the following configuration data have to be transmitted to the gauge during
the configuration phase:
Standard telegram
M
⇒
S
Standard telegram
S
⇒
M
M
⇒
S
S
⇒
M
Configuration data
ParamChannel ParamChannel Exception Status OneOfN Status Extension O
neO
fN PV Selector
Process Value UINT16 Process Value float Channel Status T
rip Relay 1-
2
1 x x 0x42,0x82,0x05,0x03
2 x x 0x42,0x84,0x05,0x08
3 x x x x 0x44,0x84,0x05,0x05, 0x05, 0x03
4 x x x x 0x44,0x86,0x05,0x05, 0x05, 0x08
2 7 x x x x 0xC4,0x87,0x8A,0x0A,0x0A,0x05,0x03
2 8 x x x x 0xC4,0x87,0x8C,0x0A,0x0A,0x05,0x08
2 9 x x x x x x 0xC6,0x87,0x8C,0x0A,0x0A,0x05,0x05, 0x05, 0x03
2 10 x x x x x x 0xC6,0x87,0x8E,0x0A,0x0A,0x05,0x05, 0x05, 0x08
201 x x x x 0x44,0x85,0x05,0x03,0x05,0x0A
202 x x x x 0x44,0x87,0x05,0x08,0x05,0x0A
2 203 x x x x x x 0xC6,0x87,0x8D,0x0A,0x0A,0x05,0x03,0x05,0x0A
2 204 x x x x x x 0xC6,0x87,0x8F,0x0A,0x0A,0x05,0x08,0x05,0x0A
206 205 0xA1,0x91
Depending on the pressure unit setting ( ≙ data unit), the following configuration
string has to be transmitted to the gauge (parameter data in hexadecimal format):
Data string (hex) Pressure unit
00 00 00 10 01 COUNTS
00 00 00 13 01 Torr
00 00 00 13 08 mbar
00 00 00 13 09 Pascal
00 00 00 00 00 TTR compatibility mode
3.7 Configuration Data
3.8 User Parameter Data
