INFICON PSG55x ATM to Medium Vacuum Gauge (Profibus) - Manual (Page 51)

tira56e1 (2010-02) PxG55x.cp
51
ID Name Structure Data type Bytes Access Store →
101 Block Type ID Simple OSTRING(n) 4 1_R
2_R N 51
102 Status
Extension
Simple UINT8 1 1_R
2_R
V 51
103 Sensor Alarm Array UINT8 2 1_R
2_R V 51
104 Sensor
Warning
Array UINT8 2 1_R
2_R
V 51
201 Pirani OFF Simple UINT8 1 1_R/W
2_R/W N 51
The Block Type ID Parameter contains an ID which describes the block type. The
block type ID of the "Pirani Transducer Block" is set to "13". The other defined
block types are listed in Appendix B.
This bit mapped byte parameter provides the following additional information of the
PxG55x sensor (PIR):
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Res. Res. Res. Res. Res. Underrange
Exceeded
Overrange
Exceeded
Reading
Invalid
Res. = Reserved
• Underrange
Exceeded
This bit is set ("1") if the ProcessValue PV is below the parameter Underrange
(ID 45) of the Pirani sensor instance (
→ 39).
• Overrange Exceeded
This bit is set ("1") if the ProcessValue PV is above the parameter Overrange
(ID 44) of the Pirani sensor instance (
→ 39).
• Reading invalid
This bit represents the logical inversion of the parameter "Reading Valid"
(ID 23) of the Pirani sensor instance (
→ 39).
This parameter contains the following information:
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Byte 0 0 0 0 0 0 0 0 SF
Byte 1 0 0 0 0 0 0 EF 0
• SF = Sensor Element Failure
• EF = Electronics Failure
This byte is always "0". (The PIR Sensor does not produce any warnings)
This parameter is used to switch the Pirani off or on (by using an automatic or
manual mode) in case of special gases used in the process.
Parameter value Description
0 Pirani is always on
1 Pirani switches off automatically
(by default at pressures above 12 mbar - depends on the
system configuration)
2 Pirani is always off
12.2 Pirani Transducer
Block
12.2.1 Block Type ID (ID 101)
12.2.2 StatusExtension
(ID 102)
12.2.3 Sensor Alarm (ID 103)
12.2.4 Sensor Warning (ID 104)
12.2.5 Pirani OFF (ID 201)
