The following attributes are supported:
ID Name Structure Data type Bytes Access Store →
16 Block Type ID Simple OSTRING(n) 4 1_R
2_R N 47
17 High Trip Point Simple According
Data Type
value (ID 29) - 1_R/W
2_R/W
N 47
18 High Trip Enable Simple Boolean 1 1_R/W
2_R/W N 47
19 Low Trip Point Simple According
Data Type
value (ID 29) - 1_R/W
2_R/W
N 47
20 Low Trip Enable Simple Boolean 1 1_R/W
2_R/W N 47
21 Status Simple UINT8 1 0_XI
1_R
2_R
D 48
26 Discrete Output
Function Block
Instance
Simple UINT8 1 1_R
2_R
N 48
28 Data Units Simple UINT16 2 2_R/W N 48
29 Data Type Simple UINT8 1 2_R/W N 48
31 High Trip Point
Hysteresis Simple According
Data Type
value (ID 29)
- 1_R/W
2_R/W
N 48
32 Low Trip Point
Hysteresis Simple According
Data Type
value (ID 29)
- 1_R/W
2_R/W
N 49
201 Factor of ATM Simple FLOAT 4 1_R/W
2_R/W N 49
202 Setpoint Mode Simple UINT8 1 1_R/W
2_R/W
N 49
The Block Type ID Parameter contains an ID which describes the block type. The
block type ID of the "Trip Point Function Block" is set to "17". The other defined
block types are listed in Appendix B.
This parameter defines the value at or above which a trip point condition will occur.
This parameter enables/disables the High Trip Point setting.
Parameter value Description
0 disable High Trip Point setting
1 enable High Trip Point setting
This parameter defines the value at or below which a trip point condition will occur.
This parameter enables/disables the Low Trip Point setting.
Parameter value Description
0 disable Low Trip Point setting
1 enable Low Trip Point setting
11.2 Trip Point Function
Block (Relay 1 and
Relay 2)
11.2.1 Block Type ID (ID 16)
11.2.2 High Trip Point (ID 17)
11.2.3 High Trip Enable (ID 18)
11.2.4 Low Trip Point (ID 19)
11.2.5 Low Trip Enable (ID 20)
