7 Device Block
The following table lists the services and parameters integrated in the Device
Block.
→ Appendix A for abbreviations
ID Name Structure Data type Bytes Acces
s Store →
15 Device Block State Simple UINT8 1 1_R/W
2_R/W N 33
16 Block Type ID Simple OSTRING(n) 4 1_R
2_R N 24
17 Device Type Simple VSTRING(n) 8 2_R N 24
18 Standard Revision Level Simple VSTRING(n) 9 2_R N 24
19 Device Manufacturer
Identifier
Simple VSTRING(n) 20 2_R N 24
20 Manufacturer
Model Number
Simple VSTRING(n) 20 2_R N 24
21 Software or Firmware
Revision Level (Profibus
Adapter)
Simple VSTRING(n) 8 2_R N 24
22 Hardware Revision Level
(Profibus Adapter)
Simple VSTRING(n) 8 2_R N 24
23 Serial Number Simple VSTRING(n) 30 2_R N 24
24 Device Configuration Simple VSTRING(n) 50 2_R N 25
25 Device State Simple UINT8 1 0_XI
1_R
2_R V 25
26 Exception Status Simple UINT8 1 0_XI
1_R
2_R V 26
27 Exception Detail Alarm Record → below - 1_R
2_R
V 27
28 Exception Detail
Warning
Record → below - 1_R
2_R
V 29
36 Run hours Simple UINT16 2 1_R
2_R N 30
202 Basic Device Firmware
Revision Level
Simple VSTRING(n) 8 2_R N 30
204 Common Exception
Detail Alarm
Array UINT8 2 1_R
2_R V 30
205 Device Exception Detail
Alarm
Array UINT8 4 (PCG)
2 (PSG)
1_R
2_R V 30
206 Manufacturer Exception
Detail Alarm
Simple UNIT8 1 1_R
2_R V 30
207 Common Exception
Detail Warning
Array UINT8 2 1_R
2_R V 30
208 Device Exception Detail
Warning I
Array UINT8 1 1_R
2_R V 30
209 Device Exception Detail
Warning II
Array UINT8 4 (PCG)
2 (PSG)
1_R
2_R V 30
210 Manufacturer Exception
Detail Warning
Simple UINT8 1 1_R
2_R V 31
211 Address Switch Simple UINT8 1 1_R
2_R V 31
212 Run hours (*4) Simple UINT32 4 1_R
2_R N 31
