SQM-160 Operating Manual
3.16 Simulate Mode
In Simulate mode, the SQM-160 simulates attached sensors. It is an easy way to
become familiar with the SQM-160 front panel controls and programming. You can
open/close the shutter to simulate deposition, zero readings, and display crystal
life. You can also test the Time and Thickness setpoint relays and LEDs.
To enter Simulate mode:
1 Press Program to enter Program mode.
2 Press Prev to enter the System Menu.
3 Press Next until SIM MODE is shown.
4 Turn the Control Knob left or right to enable and disable Simulate mode.
5 Press the Control Knob to accept the value.
6 Press Program to exit the System Menu and return to normal mode.
3.17 Defaulting the Memory
CAUTION
Performing this procedure wil default the SQM-160 to its
factory setting. All Parameters set by the user will be
deleted. Do not perform this procedure until you have
created a back up database file using SQM160 Comm.
1 Power cycle the unit while pressing and holding select buttons until an error
message appears.
1a For firmware versions before v4.10 (clears only Film parameters):
Press and hold the ZERO + XTAL LIFE + SHUTTER buttons while powering up
the SQM-160.
1b For firmware version v4.10 and higher (clears Film and System parameters):
Press and hold the ZERO + XTAL LIFE + SHUTTER + CONTROL KNOB
buttons while powering up the SQM-160.
2 "ERROR 00" message should appear. Power cycle again and no error
messages should appear.
