1.5 Unpacking and Inspection
1
If the SQM-160 has not been removed from its packaging, do so now.
2
Carefully examine the unit for damage that may have occurred during shipping.
This is especially important if you notice obvious rough handling on the outside
of the container. Immediately report any damage to the carrier and to INFICON.
3
Do not discard the packing materials until you have taken inventory and have
at least performed a power on verification.
4
Take an inventory of your order by referring to your order invoice and the
information contained in
5
To install and setup, see
.
6
For additional information or technical assistance, contact INFICON, refer to
.
1.6 Parts and Options Overview
1.6.1 Base Configurations
SQM-160 . . . . . . . . . . . . . . . . . . . . . . . . .SQM160-X-X-X
Consult the figure below for possible configurations.
Figure 1-2 SQM-160 Configurations
Technical Manual . . . . . . . . . . . . . . . . . . .074-511 on 074-5000-G1 CD
