HYDAC ETS 3000 - Manual (Page 40)

ETS 3000 User Manual 05 Sep 2008
16
12.2
ETS 3000 for External Sensor Probe
Items supplied:
1x ETS 386X-X-000-000
1 x manual
1x cable plug connector M12x1, 4-pole, for connecting the external sensor probe
1x sensor connector cable 3 m, LIYCY 4 x 0.25 mm² — screened
Connection type, external temperature sensor
Connection type, electrical
6 = 4-polp M12x1
8 = 5-pole M12x1
(connector not included)
Output
2 = 2 switching outputs
3 = 1 switching output and 1 analogue output
Sensor probe length
Modification number
000 = standard (set by manufacturer)
(connector not included)
Possible only on output models 2 and 3
Possible only on output model 5
(available only in conjunction with electrical connection type 6)
(available only in conjunction with electrical connection type 6)
ETS 3 8 6 X - X - XXX - XXX
Model
5 = 2 switching outputs and 1 analogue output
(available only in conjunction with electrical connection type 8)
8 = external temperature sensor
000 = external temperature sensor
6 = Cable connection (female) M12x1, 4-pole
