ETS 3000 User Manual 05 Sep 2008
12
10. Wiring
Diagrams
10.1 Supply Voltage and Switching Outputs
Model with 2 switching outputs
Model with 1 switching output and
1 analogue output
4-pole M12x1 connection 4-pole M12x1 connection
Model with 2 switching outputs and
1 analogue output
5-pole M12x1 connection
+
-
18 - 35 V
Imax. 1.2 A
ETS 3XX6-3
1
3
4
SP 1
RL
2
signal
Analogue
Imax. 1.2 A
ETS 3XX6-2
1
3
4 +
-
9 - 35 V
2
Imax. 1.2 A
SP 1
SP 2
Imax. 1.2 A
Imax. 1.2 A
SP 1
SP 2
ETS 3XX8-5
1
3
4
+
-
18.-.35 V 5
2
signal
Analogue
RL
