HYDAC ETS 3000 - Manual (Page 38)

ETS 3000 User Manual 05 Sep 2008
14
11.2. ETS 3000 for External Sensor Probe
Input parameters:
Measurement range: -30 .. 150 °C (-22 .. 302 °F)*
Sensor connector: Cable connection M12x1, 4-pole
Output parameters:
Accuracy (display, analogue output): ± 1.0 % FS ( + PT100 error)
Temperature drift (ambient):
≤ ± 0.015 % FS / °C (zero point and range)
Analogue output: 0 .. 10 V; ohmic resistance: min. 1 K
Ω
4 .. 20 mA; ohmic resistance:
≤ 500 Ω
acc. to -30 .. +150 °C
Switching outputs:
Type: PNP transistor output
Switching current: max. 1.2 A
Switching cycles: > 100 million
Ambient conditions:
Ambient temperature range: -25 .. + 80 °C
Storage temperature range: -40 .. + 80 °C
Rated temperature range: -10 .. + 70 °C
mark EN 61000-6-1, EN 61000-6-2,
EN 61000-6-3, EN 61000-6-4
Vibration resistance: approx. 10 g / 0 .. 500 Hz (IEC 60068-2-6)
Shock resistance: approx. 50 g / 11 ms (IEC 60068-2-29)
Other specifications:
Supply voltage: 18 .. 35 V
DC
(version with analogue output)
9 .. 35 V
DC
(version without analogue
output)
Current consumption: max. 35 mA (without switching output)
Protection type: IP 67
Display: 4-digit, LED, 7-segment, red
Character height: 7 mm
Weight: approx. 87 g (excluding connector and
probe)
FS (Full Scale) = in relation to the full measurement range
* Depending on the temperature range of the temperature sensor fitted, the indication range
of the ETS 3000 may be reduced.
