HYDAC ENS 3000 - Manual (Page 21)

E
21
11. Pin connections
11.1. Pin connections with 1 or 2
switching points
11.2. Pin connections with 4
switching points
Model with 4 switching outputs
and 2 analogue outputs
8-pole plug M12x1
Imax. 250 mA
SP 1
18 .. 35 V
+
-
U=0..10V
analogue
Temp.
R
L
1
3
8
4
ENS 3X1P-8
U=0..10V
analogue level
7
R
L
Imax. 250 mA
SP 2
2
Imax. 250 mA
SP 3
5
Imax. 250 mA
SP 4
