6.4 SETTING RANGES FOR THE SWITCHING OUTPUTS
(switching point minus switching hysteresis = switch-back point)
Probe length
in cm Measuring zone
in cm Switching point
in cm * Switching hysteresis
in cm *
25.0 17.0 0.3 .. 17.0 0.1 .. 16.5
41.0 26.0 0.4 .. 26.0 0.1 .. 25.7
52.0 36.0 0.5 .. 36.0 0.2 .. 35.6
73.0 59.0 0.9 .. 59.0 0.3 .. 58.4
The increment for all units is 0.1 cm.
Probe length
in inch Measuring zone
in inch Switching point
in inch * Switching hysteresis
in inch *
9.80 6.70 0.10 .. 6.70 0.05 .. 6.60
16.20 10.25 0.15 .. 10.25 0.05 .. 10.15
20.50 14.15 0.20 .. 14.15 0.05 .. 14.00
28.40 23.20 0.35 .. 23.20 0.15 .. 22.85
The increment for all units is 0.05 inch.
Switching point
in °C * Switching hysteresis
in °C * Increment
in °C
-23.0 .. 100.0 1.0 .. 123.5 0.5
Switching point
in °F * Switching hysteresis
in °F * Increment
in °F
-9 .. 212 2 .. 222 1
* All ranges given in the table can be adjusted by the increments shown and apply when the offset is zero.
