Appendix Appendix
110 111
Hei-VAP Advantage:
▪ Without a controller with a Rotavac valve vacuum pump
‒ ROTAVAC valve control or ROTAVAC valve tec
▪ With a controller and valve-controlled vacuum pump
‒ Vac control automatic with vacuum valve (optional Woulff bottle) and ROTAVAC
valve control
‒ Vac control automatic with vacuum valve (optional Woulff bottle) and ROTAVAC
valve tec ROTAVAC valve tec
▪ With controller and vacuum
‒ Valve Control automatic with vacuum valve (optional Woulff bottle) and vacuum
▪ With vacuum
‒ vacuum only
Unit configuration
Hei-VAP Value:
▪ With manual control valve for limiting the vacuum and a Rotavac valve vacuum pump
‒ Manual vacuum controller for limiting the vacuum with the ROTAVAC valve control
‒ Manual vacuum controller for limiting the vacuum with the ROTAVAC valve tec
▪ Without a controller with a Rotavac valve vacuum pump
‒ ROTAVAC valve control or ROTAVAC valve tec
▪ With a controller and valve-controlled vacuum pump
‒ Vac control automatic with vacuum valve (optional Woulff bottle) and
ROTAVAC valve control
‒ Vac control automatic with vacuum valve (optional Woulff bottle) and
ROTAVAC valve tec
▪ With controller and vacuum
‒ Valve Control automatic with vacuum valve (optional Woulff bottle) and vacuum
▪ With manual control valve and vacuum
‒ Manual vacuum controller for limiting the vacuum with vacuum
Hei-VAP Precision:
▪ Rotary evaporator Hei-VAP with valve-controlled vacuum pump
‒ Vacuum valve (optional Woulff bottle) and ROTAVAC valve control
‒ with vacuum valve (optional Woulff bottle) and ROTAVAC valve tec
▪ Rotary evaporator Hei-VAP with speed-controlled vacuum pump
‒ with ROTAVAC vario control
‒ with ROTAVAC vario tec
▪ Rotary evaporator Hei-VAP with vacuum
‒ with vacuum valve (optional Woulff bottle) and vacuum
▪ Expanded function of the above listed configurations
‒ Function “Auto
accurate
“ with Auto
accurate
sensor
‒ Display of the vapor temperature with vapor temperature sensor
Technical data o the vacuum box Hei-VAP
Order description Order No.
569-00100-00
Connected voltage 24 V DC
Connected load 3 W
Table 11-2: Technical data o the vacuum box
