Accessories, spare parts
Accessories, spare parts
106
107
Order description
Position
Order No.
Piece at
delivery
Threaded fitting GL 18
1
23-09-03-01-24
2
Vacuum fitting NS 29 / 32
2
514-00001-00
1
Threaded fitting GL 14
3
23-09-03-01-27
3
Connector for the threaded fitting GL 14
3
11-300-005-22
3
Valve
4
514-48000-00
1
Center piece G6
5
514-00601-00
1
Center piece G6B, plastic coated
5
514-00611-00
(1)
G6 threaded coupling
6
515-62000-00
1
Gasket G6
7
23-30-01-01-35
1
Intermediate part G6
8
22-30-01-05-02
1
Evaporator flask 1,000 ml, NS 29/32
9
514-74000-00
1
Evaporator flask 1,000 ml, NS 24/40
9
514-74000-05
(1)
Vapor tube NS 29 / 32
G6
10
514-00000-05
1
Vapor tube NS 24 / 40
G6
10
514-00020-06
(1)
Receiving flask 1000 ml, S 35/20
11
514-84000-00
1
Receiving flask 1000 ml, S 35/20, plastic
coated
11
514-84000-02
(1)
Condenser clamp S 35/20
12
515-42000-00
1
Inlet tube (PTFE-) 3.5/4.5x600
13
23-30-01-04-72
1
Threaded fitting GL10 red
14
23-30-01-04-69
1
Seal O-ring 3.2x2.5
15
23-08-06-03-26
1
Inlet pipe (stopcock)
16
514-51000-00
1
Condenser G6
17
514-23000-00
1
Condenser G6B, plastic coated
17
514-23000-02
(1)
Condenser mounting
569-00050-00
1
Table 10-4: Glassware set G6
Accessories
Order description
Order No.
230 V
50/60 Hz
Order No.
115 V
50/60 Hz
Protective hood
569-00010-00
Protective shield
569-00020-00
Vapor temperature sensor
569-00030-00
Temperature sensor Auto
accurate
sensor
569-00040-00
Vacuum pump ROTAVAC valve control
591-00130-00
591-00130-01
Condensate cooler for ROTAVAC valve control
591-00081-00
Vacuum pump ROTAVAC valve tec
591-00160-00
591-00160-01
Condensate cooler for ROTAVAC valve tec
591-00083-00
Vacuum pump ROTAVAC vario control
591-00141-00
591-00141-01
Condensate cooler for ROTAVAC vario control
591-00084-00
Vacuum pump ROTAVAC vario tec
591-00171-00
591-00171-01
Condensate cooler for ROTAVAC vario tec
591-00084-00
Vacuum box
569-00100-00
Vacuum controller VAC control automatic
569-00340-00
569-00340-01
Vacuum switch box for 3 consumers
569-00400-00
569-00400-01
Vacuum valve
569-00060-00
Woulff bottle
569-00070-00
Vacuum controller, manual
591-26000-00
Tube set
591-35000-00
Heating bath liquid (up to 180 °C) bis 220 °C (5L)
569-00600-00
PTFE 26 Vacuum seal
23-30-01-01-30
Clamping sleeve
23-30-01-05-31
Transportation safety device
11-300-006-28
Table 10-5: Accessories
