Straight rack numbering assigns consecutive dimmer numbering vertically, from top of the
rack to the bottom, regardless of phasing.
This table compares the circuit numbering of an SR3-6 filled with D20 modules when set to
straight or balanced numbering:
Racks can be set to straight through
Performing a Quick Setup, page 7
.
Rack
Phase
SR3-6
Straight Circuit
Numbering
SR3-6
Balanced Circuit
Numbering
A
1
1
2
2
3
7
4
8
B
5
3
6
4
7
9
8
10
C
9
5
10
6
11
11
12
12
