Page 3
E T C S e t u p G u i d e
DRd Dimming Engine Replacement
DRd Dimming Engine Setup Guide
Page 3 of 3
Electronic Theatre Controls, Inc.
Dimming Configuration Mismatch
Attention:
Dimming Configuration
Mismatch Detected!
Use the Dimming Rack
Configuration?
Yes
No
Help
When power is applied to the rack, the architectural control
processor (ACP) may display a dimming configuration mismatch
error on reboot. The dimming engine and the ACP both store a copy
of the dimming configuration.
For replacement of a dimming engine into a functional DRd rack
containing its original ACP, select “No”, then select “Use backup
config” when it displays. The replacement dimming engine will then load the configuration that is stored
in the ACP.
For other situations, please refer to the Paradigm or Smartlink Architectural Control Processor
Configuration Manual. The appropriate manual shipped with your processor, or you may download it
from our website at
