Introduction 2
Studio Daylight, Studio Tungsten
Some of the options include:
• Multiple dimming curve options.
• Presets and sequences for standalone operation.
• Strobe.
• Loss-of-data behavior options.
• Power regulation modes; three output options that offer a choice between maximum
light output for lower duty cycles and maximum thermal stability and output consistency
for higher duty cycles.
Figure-1.1 Components of a D40/D60 XTI Fixture.
Figure-1.2 Components of the Rear Panel.
LED array
Yoke
Trim ring
Yoke
locking
bolt
Safety
cable
loop
Power in
DMX/RDM in
and thru
Status indicators
