B
RDM Commands
40
Appendix B
RDM Commands
The following table lists the RDM commands applicable to the Desire XTI fixtures.
Feature
Get
Set
Queued
RDM Parameter ID
Parameter
Values
Enumerations
Status
Messages
Yes
No
Yes
E120_STATUS_MESSAGES
—
—
Supported
Parameters
Yes
No
Yes
E120_SUPPORTED_PARAMETERS
See RDM
E1.20-2006
—
Parameter
Description
Yes
No
Yes
E120_PARAMETER_DESCRIPTION
See RDM
E1.20-2006
—
Device Info
Yes
No
Yes
E120_DEVICE_INFO
See RDM
E1.20-2006
—
Device Model
Description
Yes
No
Yes
E120_DEVICE_MODEL_DESCRIPTION
ASCII string
for Model
Description
—
Manufacturer
Label
Yes
No
Yes
E120_MANUFACTURER_LABEL
ASCII string
for
manufacturer
label
—
Device Label
Yes
Yes
Yes
E120_DEVICE_LABEL
ASCII string
for device label
—
Factory
Defaults
No
Yes
Yes
E120_FACTORY_DEFAULTS
None
—
Software
Version Label
Yes
No
Yes
E120_SOFTWARE_VERSION_LABEL
ASCII string
for software
label
—
DMX
Personality
Yes
Yes
Yes
E120_DMX_PERSONALITY
0 thru 7
“7CH, 8CH, HSI,
HSIC, RGB,
EHSI, EHSIC”
DMX
Personality
Description
Yes
No
Yes
E120_DMX_PERSONALITY_DESCRIPTION 0 thru 7
“7CH, 8CH, HSI,
HSIC, RGB,
EHSI, EHSIC”
DMX Start
Address
Yes
Yes
Yes
E120_DMX_START_ADDRESS
1 thru 512
DMX Address
Slot Info
Yes
No
No
E120_SLOT_INFO
—
—
Slot Description Yes
No
No
E120_SLOT_DESCRIPTION
—
—
Default Slot
Value
Yes
No
No
E120_DEFAULT_SLOT_VALUE
—
—
Sensor
Definition
Yes
No
Yes
E120_SENSOR_DEFINITION
0 thru 8
“LED1, LED2,
LED3, LED4,
LED5, LED6,
LED7, LED
Ambient, Control
Ambient”
Sensor Value
Yes
No
Yes
E120_SENSOR_VALUE
0 thru 8
“LED1, LED2,
LED3, LED4,
LED5, LED6,
LED7, LED
Ambient, Control
Ambient”
Identify Device
Yes
Yes
Yes
E120_IDENTIFY_DEVICE
“0, 1"
“Stop Identify,
Start Identify”
Reset Device
No
Yes
Yes
E120_RESET_DEVICE
—
—
