17 Desire XTI Series v1.6.0 User Manual
Installation on a Wall
The Wall Mount Bracket accessory for the D40/D60 XTI fixture provides a stable mounting
position for the fixture, while providing a wire way for a clean and functional installation to
walls and other vertical surfaces.
Refer to the D40/D60 XTI Wall Mount Installation Instructions.
Power and Data Cabling Requirements
Power
The D40/D60 XTI fixture operates on AC power, 100 to 240VAC/50-60Hz. The fixture must
be connected to a non-dimmable power source in order to avoid damage to its internal
power supply and other electrical components. Dimming will damage the fixture and void
the warranty.
The fixture is completely pre-wired at the factory and there is no need for entry into the
housing.
Refer to D40/D60 XTI Installation Instructions for detailed information about installation.
Europe North America Mains
Brown Black Live
Blue White Neutral
Yellow/green Green Ground
C A U T I O N : The fixture must be grounded and wired in accordance with national, state and
local electrical codes. Failure to do so may result in serious personal injury.
