39 Desire XTI Series v1.6.0 User Manual
Quick Setups
Various pre-programmed combinations of operational settings are available to quickly get
you started. These settings are specifically created for different situations and are easily
accessible with an RDM configuration tool or RDM lighting control device.
Quick Setups (Vivid, Lustr+, Fire, Ice, and Studio HD)
Quick Setups (Studio Daylight, Studio Tungsten)
Quick Setup Description Profile Features
General
General lighting:
All-purpose settings for most lighting
applications.
The default setup except for fixtures with
Studio LED arrays.
Direct
control
• Standard dimming curve
• Regulated output for brightness
consistency
• Individual color channels plus master
intensity control
• Allows for native color space
crossfades
• Output is NOT color-calibrated
Stage
Theatrical lighting:
Tungsten-like performance and precise
color-control.
Uses the most DMX channels of all quick
setups.
HSI
Plus 7
enabled
• Incandescent dimming curve
• Regulated output for brightness
consistency
• White point: 3200K
XT Arch
Outdoor and extreme environments:
Longevity and reliability in applications
with limited access.
High degree of output consistency and
protection against temperature swings.
HSI
• Standard dimming curve
• Protected output for high-heat
environments
• Reduced overall brightness
• White point: 3200K
High Impact
Concerts and High Impact lighting:
Enables quickest response, simple RGB
control and strobe channel for maximum
effect usage.
RGB
• Quick dimming response
• Boosted output for maximum intensity
• Reduced consistency of output
• White point: 5600K
Studio
Video or film lighting:
Enables quick, comprehensive control of
white light via DMX or RDM.
High-quality white-light output.
Studio
• Linear dimming curve
• Regulated output for brightness
consistency
• Variable white point of 2950 to 6500K
• Variable green/magenta balance (tint)
The Studio Quick Setup is operational in
all fixtures for excellent white light
performance. It is the default setting for
Studio fixtures.
Quick Setup Description
Control
Channels
Features
Studio
Video or film:
The default setting for Studio Daylight and
Studio Tungsten fixtures. 3 –
Intensity,
Strobe
• Linear dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Stage
Theatrical lighting:
Behaves like a theatrical fixture in control
and dimming performance. 3 –
Intensity,
Strobe
• Incandescent dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Single
Channel
Architectural installations:
Most streamlined settings for applications
with limited control options.
1 – Intensity
• Standard dimming curve
• Regulated output for brightness
consistency
