Installation and DMX Profiles 24
DMX Footprints and Channel Mapping
Vivid, Lustr+, Fire, Ice, Studio HD
Studio Tungsten and Daylight
Channel HSI HSIC RGB Studio Direct
1 Hue Hue Red Intensity Color 1
2 Hue fine Hue fine Green Color temp Color 2
3 Saturation Saturation Blue Tint Color 3
4 Intensity Intensity N/A N/A Color 4
5 Strobe* Strobe* Strobe* Strobe* Color 5
6 N/A Color temp N/A N/A Color 6
7 Plus7 on/off * Plus7 on/off * Plus7 on/off * Plus7 on/off * Color 7
8 Plus7 - (1) * Plus7 - (1) * Plus7 - (1) * Plus7 - (1) * Intensity
9 Plus7 - (2) * Plus7 - (2) * Plus7 - (2) * Plus7 - (2) * Strobe a
10 Plus7 - (3)
*
Plus7 - (3)
*
Plus7 - (3)
*
Plus7 - (3)
* N/A
11 Plus7 - (4) * Plus7 - (4) * Plus7 - (4) * Plus7 - (4) * N/A
12 Plus7 - (5) * Plus7 - (5) * Plus7 - (5) * Plus7 - (5) * N/A
13 Plus7 - (6) * Plus7 - (6) * Plus7 - (6) * Plus7 - (6) * N/A
14 Plus7 - (7) * Plus7 - (7) * Plus7 - (7) * Plus7 - (7) * N/A
Channel Control
1 Intensity
2 White point
3 Tint
4 –
5 Strobe
