Gold Drum HV Installation Guide (EtherCAT and CAN)
Technical Information
MAN-G-DRUMHVIG-EC (Ver. 1.202)
22
3.2. Technical Data for 800 V Drive
Feature
Units 35/800
50/800
R70/800
R100/800
Minimum supply voltage
VDC
*For S, T, or A option
= 95
Nominal supply voltage
VDC
560 for 400 VAC
680 for 480 VAC
Maximum supply voltage
VDC
780
Maximum continuous power
output
kW
22.5
32.5
45
65
Efficiency at rated power (at
nominal conditions)
%
> 98
Auxiliary supply voltage option
VDC
18 to 30 VDC (only in S, T, or A option)
Auxiliary power supply
VA
≤5 VA without external loading
≤7 VA with full external loading
Continuous current limit (Ic)
Amplitude sinusoidal/DC
trapezoidal commutation
A
35
50
70
100
Continuous RMS sinusoidal
commutation current limit (Ic)
A
25
35
50
71
Peak Current
A
70
100
No Peak
No Peak
Weight
g (oz)
1.65 Kg (58.202 oz)
Dimensions
mm (in)
180 x 142 x 75.2 (7.08" x 5.53" x 2.96")
Digital in/Digital out/ Analog in
6/4/1
Mounting method
Panel / Wall Mounted
For both above Technical Data tables
*See page 25 for details on the part number. The S, T, or A option appears in models where
there is a 24 V control supply. If there is a 0 or 1 option, the control power supply operates
from the main power.
Note on current ratings:
The current ratings of the Gold Drum HV (High Voltage) are
given in units of DC amperes (ratings that are used for trapezoidal commutation or DC motors).
The RMS (sinusoidal commutation) value is the DC value divided by 1.41.
