CiDRA SONARtrac HD GVF-100 - Manual (Page 69)

Copyright © 2006 CiDRA Corporation Page 9-16
20675-02 Rev 01
Table 14 Transmitter Menu Tree Software Release 03.03.XX
Level 1
Level 2 Level 3 Range Description
Sensor
Serial #
0000000
Serial number of sensor
band
ID/Wall
ID: 1- 100 in (25.4-
2540mm)
Wall 0 – 100 in (0 to
2540 mm)
Pipe inner diameter and
wall thickness
Size/Sched 2 to 36" size; schedule Pipe size & schedule Pipe Size
OD/Wall
ID: 1- 300 in (25.4-
7260mm)
Wall 0 – 100 in (0 to
2540 mm)
Pipe outer diameter and
wall thickness
Pipe Material SST, CS, PVC, Custom
Enters the pipe
modulus, kilo-Pascal
Spec Gravity 0 - 999999
Enters the specific
gravity; default water at
25 °C and 14.7 psia
SOS (ft/s) 0 - 999999
Sound speed in media
of interest; ft/sec;
default water at 25 °C
and 14.7 psia
Fluid
Properties
Viscosity
0.0000 e-38 to
9.9999 e+38
Enters the liquid
viscosity in Pa-sec;
default water at 25 °C
and 14.7 psia
Pressure +/- 0-999999
Process pressure; PSIg,
Barg, kPag
Temperature
-999 to +999C
-1766 to 1830F Process temperature;
°C or F
Pressure Sel Fixed, Sensor #1 or #2
Allows for selecting a
fixed pressure input or
using the inputs of
sensor #1 or #2
Temperature
Sel
Fixed, Sensor #1 or #2
Allows for selecting a
fixed temperature input
or using the inputs of
sensor #1 or #2
Altitude -50,000 to +50,000
Process pipe altitude
above / below sea level;
feet or meter
C0 term
0.0000 e-38 to
9.9999 e+38
First term coefficient
C1 term
0.0000 e-38 to
9.9999 e+38
Second term coefficient
Basic Config
Calibration
C2 term
0.0000 e-38 to
9.9999 e+38
Third term coefficient
