9.5.1.3 Display Examples
The following figure shows the display when the system is collecting
data to calculate a measurement. The ‘------‘ indicates the system is
unable to make a measurement, or an internal parameter was
changed that has caused the system to re-initialize.
V
F
------ gpm
G
V
F
------- %
VF INITIALIZE MODE /
Figure 55 Initialization Mode
In the following display the system is making a measurement. The
flow rate is 2281.6 gpm and the entrained air of GVF reading is 2.016
%. The quality metric associated with the GVF measurement (SQ)
is .72.
V
F
2281.5 gpm
G
V
F
2.016 %
SQ .72 /
Figure 56 VF & GVF-100 Measurement Screen
9.5.2 Menu Mode
This mode of operation permits the user to adjust various settings on
the SONARtrac
TM
transmitter as well as perform multiple diagnostic
tests. The menu system is set up in a tree format, with seven top level
categories (illustrated in bold print below) that can each have up to
two levels of sub menus. The menu structure is shown in the table on
the following page.
