1 - 6 System Map: LCD Panel Open & Top View
Quick Start Guide
1
System Map: LCD Panel Open & Top View
Figure 1 - 2
LCD Panel Open
& Top View
1. Optional Built-In PC
Camera
2. LCD
3. LED Status Indicators
4. Touch Sensor
Instant Keys
5. 8 * Gaming Keys
6. Keyboard
7. TouchPad and
Buttons
8. Fingerprint Reader
Module (optional)
9. LED Power Indicators
10. LCD Panel Color
LED
See
for a more
detailed description of the
ports & jacks etc.
2
1
6
7
8
4
5
3
9
10
Wireless Device
Operation Aboard
Aircraft
The use of any portable elec-
tronic transmission devices (e.g.
WLAN or Bluetooth) aboard air-
craft is usually prohibited. Make
sure any wireless modules are
OFF if you are using the comput-
er aboard aircraft.
Use the appropriate function key
combination/Touch Sensor Key
to toggle power to any wireless
modules, and check the indica-
tors to see if any modules are
powered on or not (see
Table 1
- 2, on page 1 - 8
).
