Setting Up SATA RAID Mode 7 - 5
7
RAID Setup (Intel Matrix)
1. As the computer starts up press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to advance to the next
field.
4. Specify (use the up and down arrow keys) the RAID level (see Table 7 - 1, on
page 7 - 3 ) and then press Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by pressing Y.
RAID Volumes:
None Defined
Physical Devices:
Port Drive Model
Serial # Size Type/Status(Vol ID)
2 FUJITSU MHY2120B K404T812P22B 111.7GB Non-RAID Disk
4 FUJITSU MHY2120B K404T7C2KJ14 111.7GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM v9.5.0.1008
Copyright (C) 2003-09 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]]
[ DISK/VOLUME INFORMATION ]
[ ] Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
1. Create RAID Volume 4. Recovery Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
Figure 7 - 1
Intel(R) Rapid
Storage Technology
Option ROM
