Part 6: REPLACEMENT PARTS
MRAN 90 ° TABLE AND DRAIN ASSEMBLY
Fig. 6.21 Part Part Description
Item No. No. Qty.
1 202392 Pin, roller ............................................................................................ 2
2 106138 Roller, pawl bar .................................................................................. 2
3 106558 Pin, cotter (1/8" x 3/4") ...................................................................... 2
4 314352 Bracket, roller ..................................................................................... 2
5 100735 Bolt (1/4-20 x 5/8") ............................................................................ A/R
6 107967 Nut, grip (1/4-20 w/nylon insert) ....................................................... A/R
7 107966 Nut, grip (10-32) ................................................................................ 4
8 202381 Roller, crosshead ................................................................................ 1
9 100769 Screw, set (3/8-16 x 3/4" dog point)................................................... 1
10 202386 Crank .................................................................................................. 1
11 100868 Stud, roller .......................................................................................... 1
12 107089 Nut, jam 1/2-13 .................................................................................. 1
13 100007 Screw (10-32 x 3/8) Truss hd. ............................................................ 1
14 104925 Washer (1/4" x 1") .............................................................................. 1
15 100771 Screw, set (1/4-20 x 1/4) Socket hd ................................................... 1
16 103180 Ring, wiper ......................................................................................... 1
17 100153 Bolt (3/8-16 x 1") Hex hd. ................................................................. 4
18 107864 Washer, packing ................................................................................. 1
19 107863 Outlet, waste ....................................................................................... 1
20 304816 Strainer, 6".......................................................................................... 1
21 106482 Washer, lock 1/4" split........................................................................ 1
22 10003 Nut, plain 1/4-20 SST ........................................................................ 1
23 314354 Stiffener, shaft .................................................................................... 1
24 100747 Bolt (1/2-13 x 1") ............................................................................... 1
25 106026 Washer (1/4" x 5/8" x 1/16") SST ...................................................... A/R
26 100141 Nut, grip (1/4-20) SST ....................................................................... A/R
27 112145 Receptacle (Optional for roller table only) ........................................ 1
28 320261 Bracket, cord (Optional for roller table only) .................................... 1
29 107865 Locknut .............................................................................................. 1
30 107866 Washer, packing ................................................................................. 1
31 107867 Nut, outlet pipe ................................................................................... 1
32 109283 Tailpiece, straight ............................................................................... 1
* Please note that the direction of the crank arm should be clockwise when looking down from the
top of the table.
