CHAMPION USN72 - Manual (Page 117)

89
Part 6: REPLACEMENT PARTS
DRAIN AND OVERFLOW ASSEMBLY
Fig. 6.15 Part
Item No. No. Part Description Qty.
1 112287 Tee 1-1/2" copper, solder connect ...................................................... 2
2 111353 Elbow, 1-1/2" copper, solder connect................................................. 1
3 109110 Elbow 1-1/2" copper x 1-1/2" FTG .................................................... 1
4 102505 Plug 3/4" brass ................................................................................... 1
5 109062 Adapter, 3/4" FTG, x 3/4" FPT copper .............................................. 1
6 109072 Valve, ball 1-1/2" solder ..................................................................... 1
7 113297 Adapter, 1-1/2" x FPT x 1-1/2" FTG copper...................................... 3
8 109111 Tee reducer 1-1/2" x 3/4" x 1-1/2" copper ......................................... 1
9 206139 Flange, drain USN72 mod.................................................................. 2
10 202819 Tube 1-1/2" x 2-3/4" copper ............................................................... 1
11 206137 Tube 1-1/2" x 13-5/8" copper ............................................................. 1
12 206136 Tube 1-1/2" x 8-3/8" copper ............................................................... 1
13 206138 Tube 1-1/2" x 7-1/2" copper ............................................................... 1
14 205598 Tube 1-1/2" x 4-7/16" copper ............................................................. 1
15 109479 Union 1-1/2 copper, solder connect ................................................... 1
16 100739 Bolt, 5/16-18 x 3/4" Hex hd ............................................................... 16
17 106013 Washer, lock, 5/16" ............................................................................ 16
18 102376 Washer, flat, 5/16" .............................................................................. 16
19 108345 Gasket ................................................................................................. 4
20 202191 Flange, drain ....................................................................................... 4
21 304816 Screen, drain ....................................................................................... 2
22 107967 Nut, grip, 1/4-20 ................................................................................. 2
23 323237 Assembly, overflow............................................................................ 2
24 107136 Bolt, 10-32 x 3/8" Hex hd .................................................................. 4
25 104985 Nut, 10-32 .......................................................................................... 4
26 B2857 Cover assy. ......................................................................................... 2
— 325218 Assembly, drain .................................................................................. 2
