Part 6: REPLACEMENT PARTS
77b
ELECTRIC TANK HEAT
(For machines beginning with S/N J1872 and above)
Fig. 6.9b Part
Item No. No. Part Description Qty.
1 317165 Cover, heater box, metal .................................................................... 2
2 100007 Screw (10-32 x 3/8”)............................................................................ 8
3 317166 Heater box, metal ............................................................................... 2
4 107033 Washer, flat ......................................................................................... 16
5 107967 Nut (1/4-20), grip with nylon insert ................................................... 16
6 107846 Heater Element-10KW (480V) .......................................................... A/R
7 108345 Gasket, heater ..................................................................................... 5
8 109638 Flange, blockoff ................................................................................. 1
9 112257 O-ring ................................................................................................. 1
10 100740 Bolt (5/16-18 x 1”), hex cap ............................................................... 24
11 102376 Washer, flat (5/16”) ............................................................................ 48
12 106013 Washer, lock (5/16”) medium split..................................................... 24
13 100154 Nut (5/16-18), hex finish .................................................................... 24
14 109069 Thermostat, with capillary ................................................................. 1
15 201041 Washer, flat (7/8" ID x 1/8") .............................................................. 1
16 109034 Gasket (1/2 NPT) plug ....................................................................... 1
17 100547 Locknut (1 1/2 NPT) .......................................................................... 1
18 111092 Switch, float ....................................................................................... 1
19 111151 C-clip .................................................................................................. 2
20 110750 Gasket, float switch ............................................................................ 1
21 107589 Washer, lock (1/2") ............................................................................. 1
22 104584 Nut, plain (1/2-13) .............................................................................. 1
23 328193 Wireway box, RH................................................................................ 1
24 328194 Wireway box, LH................................................................................ 1
25 328190 Wireway cover ................................................................................... 2
26 108954 Nut (6-32), w/nylon insert................................................................... 4
27 110561 Thermostat, high limit with reset ....................................................... 2
28 109069 Thermostat, with capillary ................................................................. 2
29 106382 Screw (6-32 x 3/8”), slot truss............................................................ 4
30 113777 Block, Terminal, 18-Pole, Wash Tank................................................ 1
31 113778 Block, Terminal, 26-Pole, Rinse Tank................................................ 1
32 111833 Block, Terminal, 3P 175A .................................................................. 2
33 332634 Weldment, Thermostat Adjustment Guide ......................................... 1
34 332635 Plate, Cover, Thermostat Adjustment ................................................. 1
*
* Note:
Install Qty.1, P/N 109638, Flange Block-off and Qty.1 P/N 112257, O-ring in place of heater element.
Wash Tank Heat installations use Qty.2, P/N 107846 10kW heaters.
Rinse Tank Heat installations use Qty.3, P/N 107846 10kW heaters.
