CCTV Camera Pros iDVR-PRO A Series DVRs - Manual (Page 39)

English | 39
To add a sequence
1. Click in the bottom of the screen.
2. When the "ADD" dialog appears, enter a title using the
virtual keyboard.
3. Enter the name of the sequence and click .
4. When the dialog appears, click
.
5. When the "SEQUENCE SETUP" dialog appears, select
a split mode that you want to add from .
6. If the selected split mode is displayed on
CONFIGURE>, select a channel you want to display
in each split screen.
7. Click .
The set sequence mode is confirmed and will be
added to the Add Sequence list in order
8. When done, click in the bottom of the
screen.
After the sequence type is saved, you will return to
the previous screen.
9. Place your mouse cursor over a desired tile of added
Sequence, right click on it or press the [ENTER] button of the remote control to edit or delete it.
