English | 15
Ins
tall
atio
n
Basic Layout
J Since the cable quality may affect directly to the video quality depending on the distance between the camera
and DVR, it is recommended to consult an authorized installer when installing the DVR.
VGA
DC 12V
ETHERNET
HD MONITOR
IN 1 IN 2 GND IN 3 IN 4 NO
COM NC D+ D-
ALARM IN
RELA Y RS485
NTSC
PAL
AUDIO
IN
AUDIO
OUT
1/2
3/4
AUX
VIDEO IN
DC 12V
Power
Control
Devices
Speaker MIC Alarm Sensor
SPOT
Monitor
Monitor
960H
Camera
Full HD (RGB)
Monitor
IP Router
or HUB
