Appendix
Appendix
Specification
Item 4CH 8CH 16CH
VIDEO
INPUT SIGNAL NTSC/PAL NTSC/PAL NTSC/PAL
MAIN MONITOR HDMI / VGA HDMI / VGA HDMI / VGA
SPOT OUT
Analog 1CH(1Vpp, 75Ohm)
x1
Digital 1CH/4CH (1Vpp,
75Ohm) x1
Digital 1CH/4CH (1Vpp,
75Ohm) x1
LOOP THROUGH NO NO NO
MOTION DETECTION YES YES YES
AUDIO
INPUT SIGNAL 4CH(10KOhm, 2.8Vpp) 4CH(10KOhm, 1Vrms) 4CH(10KOhm, 1Vrms)
OUTPUT SIGNAL 1CH(600Ohm, 2.8Vpp) 1CH(600Ohm, 1Vrms) 1CH(600Ohm, 1Vrms)
CODEC G.711 G.711 G.711
RECORDING
CODEC H.264 H.264 H.264
REC. RATE
Up to 120FPS/
100FPS @ 960H
Up to 240FPS/
200FPS @ 960H
Up to 480FPS/
400FPS @ 960H
Up to 120FPS/
100FPS @ 2CIF
Up to 240FPS/
200FPS @ 2CIF
Up to 480FPS/
400FPS @ 2CIF
Up to 120FPS/
100FPS @ CIF
Up to 240FPS/
200FPS @ CIF
Up to 480FPS/
400FPS @ CIF
REC. RESOLUTION CIF, 2CIF, D1, 960H CIF, 2CIF, D1, 960H CIF, 2CIF, D1, 960H
ALRM I/O
ALARM INPUT
4CH, Pulled up to 5V via
10KOhm
4CH, Pulled up to 5V via
10KOhm
4CH, Pulled up to 5V via
10KOhm
ALARM OUT 1CH, RELAY(5V, 35mA) 1CH, RELAY(5V, 35mA) 1CH, RELAY(5V, 35mA)
STORAGE
INTERNAL HDD 1EA 2EA 2EA
EXTERNAL
STORAGE
NO NO NO
INTERNAL ODD NO NO NO
