Anchor EVENT SERIES - PROFILE SIZE: 20M - 220X100X4 - 3M UPRIGHTS User Manual
Page 8
Spanning the world.
BT 2000 240/300 570/627
7
1.2 Construction tools
The construction and dismantling has to be done with the respective
construction tools.
Special provided tools for the construction:
1.2.1 Measuring rod
1.2.2 Mounting rod 6m,
1.2.3 Mounting rod 4m,
1.2.4 Leading-in conductor for covers 2x
1.2.5 Bracing devices for tent‘s covers
More construction tools and working substance prepared for the structure:
At least 3x traction cable with carabine swivel (at least 250 daN carrying
force)
2x double ladder equivalent the height of tent’s side
1x spanner SW 17
2x spanner SW 24
1x handspike
2x aboutsledge
10x squared beam 80 x 80 x 400 mm
1x pincers
2x measuring tape 30 m
1x directional cord (at least double the length of the tent)
1x optional: peg puller (for dismantling recommended)
1x Crane or fork stacker with telescope jib with hoisting height 8-10m
mounting drawing cage.
