Spanning the world.
BT 2000 240/300 570/627
37
5.2 Stretching of the roof cover (model with fixed tensioning)
There are 2 variations to distinguish among the roof covers:
a) With fixed bracing aa) –With stretch strap aaa) –With thread bracing
b) With rubber tensioning
If your tent has the model b) rubber tensioning, then skip this point and go
on with the mounting steps of point 5.3.
Prepared assembling auxiliaries:
Building components:
Bracing pipe with angle
Bracing pipe
Stretch strap with ratchet or thread bracing
Clow hooks
Connection profiles
5.2.1 Feed the 4 bracing pipes with the angles into the kits of the outer roof
covers. The angles have to show upwards and to the gable side of the
tent (pic. 20).
5.2.2 Feed the bracing pipes without angle into the kits of each roof cover.
5.2.3 Type stretch strap: set the connection profiles each on the bracing
pipes between the covers and hang up the loop to the bracing device.
Hang up the mounting hooks of the bracing device to the boring of
the legs (pic. 21).
5.2.4 Type stretch strap: pull the bracing device with the aid of the ratchet
to stretch at the same time the roof cover in both of the sides.
5.2.5 Type thread bracing: set the tensioning devise to the free below keder
groove of the roof beam and push it until the limit stop. Place the
connection profiles on the bracing pipes (pic. 22).
5.2.6 Type thread bracing: turn on the stretch bolt and stretch steady the
roof covers.
5.2.7 Repeat point 5.2.4 resp. 5.2.5 for all the roof covers.
5.2.8 Connect the tabs of the roof covers, with buckle straps or bands with
the equivalent opposite parts of the next roof cover (pic. 23).
