Spanning the world.
BT 2000 240/300 570/627
25
4 Erection of the tent
You need a self-propelling crane or a fork stacker with telescope for the
putting of the tent (see also point 1.2).
Protect the dangerous spots during lifting.
Do not work under hanging load!
4.1.1 Put the legs of the mounted beams in to the already placed
baseplates types B. Adjust the boring, bolt the baseplate and the legs
of bay with the pin. Insert the pin from the inside of the tent to
outside. Fix tightly the pin with a R-clip.
4.1.2 Place the gable supports to their receivers of the end beams and if
provided place them the ridge connectors and bolt them. Fix them
tight by screwing down the safety bracket (pic. 18). After the
adjusting of the bay, the gable supports can be placed to the
baseplates.
4.1.3 Feed two load belts into the gravity center of bay (pic. 3) to the beams
and lift the bay with the aid of the crane or fork stacker. Place to both
sides the wires of the wind bracings. Now fix tightly to both sides the
bay with the wires after the setting upright.
4.1.4 Lift the bay slowly and take care that is not going to be twisted.
4.1.5 Place the bay vertical and fix it tight with the wires of the wind
bracings. The helpers are supporting the legs. Lay the wires of the
wind bracings to both sides and fix them tight by beating in the
anchors.
4.1.6 Disharge carefully the load belt and hung it off.
4.1.7 Follow the points 4.1.3 and 4.1.4 also for the 2. bay. After erecting
the 2. bay, leave them on the hooks.
4.1.8 Hang up the eave- and intermediate purlin. Hang up to the hooks
which are provided with the radius each of the below intermediate
