Spanning the world.
BT 2000 240/300 570/627
3
Index
1 Introduction..............................................................................4
1.1 General notes ...................................................................................... 5
1.2 Construction tools ............................................................................... 7
2 Staightening of the tent any laying of the baseplates.................8
2.1 Laying of the baseplates ...................................................................... 8
3 Construction of the tent..........................................................13
3.1 Pre-assembly of the legs, beams and wind bracings.......................... 13
3.2 Mounting of the components............................................................. 18
3.3 Mounting of the wind bracings .......................................................... 22
4 Erection of the tent .................................................................25
4.2 Mounting problems and their causes ................................................. 32
4.2.1 The corner- and middle legs do not fit to the baseplate receiver . 32
4.2.2 The baseplate pins cannot be fixed tight ..................................... 32
5 Mounting of tent’s covers .......................................................34
5.1 Pulling up the roof cover.................................................................... 34
5.2 Stretching of the roof cover (model with fixed tensioning) ................. 37
5.3 Stretching of the roof cover (model with rubber tensioning) .............. 39
5.4 Pulling in the gable covers (gable triangle)......................................... 40
5.5 Pulling in the sides- and gable walls.................................................. 40
5.6 Mounting of the ground rail (if provided) ........................................... 42
6 Dismantling ............................................................................43
7 Service notes ..........................................................................44
7.1 Construction of the tent..................................................................... 44
7.2 Bedding and transport ....................................................................... 44
7.3 Routine visual inspection ................................................................... 44
8 Ratings ...................................................................................45
8.1 Construction of the tent..................................................................... 45
8.2 Tent covers........................................................................................ 47
8.3 DIN ISO Normen................................................................................. 47
