Anchor PZ (PARTY) SERIES - PROFILE SIZE: 94MM X 48MM ADDENDUM - HEX END - Manual

Width of Structure
(6M or 9M)
Baseplates must be parallel. Stake
each baseplate.
Assemble main arch as noted in the standard
PZ instruction manual.
Use (4) installers to raise beam to vertical.
After beam is raised, hold in place using (2)
installers.
Place stepladder
between baseplates,
under ridge.
Assemble Main Arch
1
Figure 1a
Main Arch
PZ-Series Hex End Appendix
Use this Appendix with the Anchor Structure PZ Manual
Hex ends may be used together or
as an end to a standard rectangular
building.
HEX END RIDGE PLATE. Use
only on the side of the hex end.
Both sides if this is a Hex Structure.
EC 4582 PZHE 0912 PZHE 0912
