3 Construction of the tent
3.1 Pre-assembly of the legs, beams and wind bracings
Prepared assembling auxiliaries:
Construction tools:
Building components:
Squared beams Endbeams
Crowbar Middlebeams
Legs
Ridge connectors
Safety stanchion for sliding eave connection
Pin Ø 20 with washer
Ridge pin Ø 16 with washer
Equivalent number of wind bracings (see 3.3)
Intermediaite purlins
Ridge purlins
Eave purlins
Gable supports
Gable eave rails
Ridge struts
Mounting of the legs and beams
Identify and assign all the components according to the pic. 5, 6 and 7.
The components are according to the pictures. On placing proceed as
follows.
First mount only the two first bracings.
3.1.1 Lay each of the corner- and middle legs between the baseplates.
3.1.2 Lay the end- and the middle beams between the baseplates.
3.1.3 Lay the ridge connector.
3.1.4 Lay and allocate the ridge struts.
3.1.5 Lay and allocate the respective mounting pins (pic. 5 - 7).
3.1.6 Lay and allocate to the endbay the gable supports and gable eave rails.
3.1.7 Lay and allocate the intermediate-, ridge- and eave purlins.
