BT 2000 240/300 570/627

8 Ratings

8.1 Construction of the tent

All the dimensions have been given axial
Tent’s length:

min. 10,0 m

Max. length:

any enlarge in grid possible

Tent’s width:

20,0 m

Ridge height:

5,70 m / 6,27 m

Side height:

2,40 m / 3,00 m

Roof inclination:

18°

Bay distance middle:

5,0 m

Leg profile:

220 x 100 mm

Beam profile:

220 x 100 mm

Ridge purlin profile:

130 x 70 mm

Intermediate purlin profile:

60 x 60 mm

Eave purlin profile:

130 x 70 mm

Gable support profile:

130 x 70 mm

Gable eave rail profile:

130 x 70 mm

Material main construction:

aluminium, anodic oxidation

Material connection parts:

steel, zinced

Kind of connection (legs/beam):

sliding eave connection

Requisite foundation pressure:

> 0,2 MN/m² (see static)

Design load: (see static)

wind load 100 km/h

0,5

kN/m²

Longest piece of part:

10,7 m

Anchorage: earth-anchor

∅

25 mm x 1000 mm /

800 mm
