2.1.4 Mount the measuring rod with baseplate pins to the baseplate
1 (6-
hole)
(pic. 3).
2.1.5 Mount the measuring rod to the baseplate
2 (6-hole) with the flange
pin
(pic. 3).
2.1.6 Adjust the baseplate
2 parallel to the directional cord and mount it
with 2 earth-anchors.
2.1.7 Stretch the directional cord across the tent’s width and adjust it by
estimating by sight right angle.
2.1.8 Measure the tent‘s width from the middle of the baseplate
1 until the
middle of the baseplate 3 (6-hole) and adjust the baseplate (pic. 3).
2.1.9 According to the picture measure to the mounted measuring rod
between baseplate 1 and baseplate 2 exact 3,0m and mark it (point
A). Take the measurements with the directional cord between the
baseplates
1 and 3 exact 4,0m and mark it (point B) (pic. 4).
2.1.10 There ought to be a diagonal of 5,0m between the points A and B
(pic. 4). You have to place the directional cord in a way that between
the baseplates
1 and 3 the dimension is 5,0m.
2.1.11 Adjust the baseplate 3 again to the directional cord if necessary.
Check once more the tent’s width between the baseplates 1 and 3.
Mount the baseplate 3 with 2 earth-anchors.
2.1.12 Dismantle the baseplate pin of the baseplate 1 and turn down the
measuring rod on the baseplate 2 (pic. 4).
2.1.13 Adjust the baseplate
4 (6-hole) to the directional cord and mount the
measuring rod. Fix the baseplate with earth-anchors.
