3.3 Mounting of the wind bracings
Mount the wind bracings (pic. 11).
Do not move them out.
Mount each of wind bracing to the first and to both last fields of the tent.
They must not be more than 6 free fields between the bracings.
If more than 6 free fields are built, then an additional wind bracing has to be
mounted.
See the picture 11 for the mounting of the brace fields.
In principle:
The wires of the wind bracings have to be mounted in the way that the
toggle-type fasteners are always set at the bottom part of the wire.
By the pre-assembly the roofing bonds have to be fastened only to a bay.
3.3.1 Prepare the wires of the wind bracings (accord. pic. 11) to the
equivalent fields.
3.3.2 Screw on the toggle-type fasteners of the side (do not screw them on
at all) Unhook the shackel.
3.3.3 Mount the ring bolts M16x120 of the roofing bonds to the ridge
connectors and fix them tight (pic. 9).
3.3.4 Feed from below the ring bolts into the endbay and screw the nut from
above, feed from above the ring bolt inside to the bay and screw it
from below with the nut. Hook the shackel (pic. 12).
3.3.5 Mount the side bonds to the corner- and middle legs according the
above instructions (pic. 8).
