Spanning the world.
BT 2000 240/300 570/627
18
3.2 Mounting of the components
3.2.1 Connect together each of the left and right end- and middle beams
through pushing of the ridge connectors. The placing of timbers
makes the mounting easier. Place the pins (pins Ø 16 with washers) to
the equivalent borings. Pay attention that the pins fixed tightly (pic. 9).
3.2.2 Push the mounted beams into the receiver of the sliding eave
connection to the legs and push them until the limit stop. Place the
safety pin ∅ 14 to the equivalent boring through the open side of the
profile of beam (pic. 8).
3.2.3 Feed each ridge strut into the receivers and bolt them with pins (pins Ø
20 with washer). Fix the pins tight by screwing on behind the safety
bracket (pic. 10).
3.2.4 Place the legs of the bay (mounted beams and legs) into to the
baseplates. Bolt them with baseplate pins and fix the pins tight by
screwing on behind the safety bracket.
3.2.5 Mount the 2. bay according the instruction.
3.2.6 Mount the rest of the bays according to the points 3.2.1 and 3.2.2.
