5.4 Pulling in the gable covers (gable triangle)
The covers for the cover gable are each composed of 2 gable covers, an eye-
and a loop side. The inside area of the tent is marked through the sewing of
the loops that turns down to the inside and bond resp. this is the overlapping
of the sides, which makes a right angle.
The outsides have been marked with the signboard RÖDER (if provided)
and/or with colour lines (if provided).
5.4.1 Feed with the keder the gable triangles into the above keder groove of
the endbeams. Hang up 1-2 wires into the traction eye. 1-2 mounting
helpers are pulling from the mounting drawing case or the movable
platform to the wires of the triangle covers until the ridge (pic. 26).
5.4.2 Cord up each of the both gable covers according to (pic. 30) from the
top to bottom and bind them on the tent inside. Bind the last loop
(pic. 27).
5.4.3 Repeat the points 5.4.1 and 5.4.2 for the opposite gable side.
5.5 Pulling in the sides- and gable walls
Every gable of the gable curtains is composed of wide and small roof covers
and each of them has been marked in a lower corner (GV = Gable wall).
The side walls will be fixed to the longest side of the tent and they have been
also marked (SV = Side wall).
Apply in the same way as the gable covers in setting through loops- and eye
sides.
5.5.1 Allocate the covers and lay them. The cranked hooks must be laying
upwards. The cranked hooks are facing to the outside of the tent by
the side walls, any by the gable walls are facing to the inside of the
tent (pic. 28).
5.5.2 Feed the keder upwards of the cover to the keder groove of the tent’s
legs and push it totally upwards.
