3 Configure Hotspot to Network
13 AirLive WIAS-3200N v2 User’s Manual
3
3. Configure Hotspot to
Network
3.1 Network Requirement
In the general network environment, the main role of WIAS-3200N v2 is a gateway that
manages all the network access from internal network to Internet. Thus, the first step is to
prepare an Internet connection from your ISP (Internet Service Provider) and connect it to
the WAN port of WIAS-3200N v2.
3.2 WAN
There are 3 connection types for the WAN Port: Static IP, Dynamic IP, PPPoE and PPTP.
Now, let us discuss how to configure WAN port. Please click on System > WAN and follow
the below setting.
3.2.1 Static IP
The administrator can manually setup the WAN IP address when static IP is available/
preferred.
