Technical Parameters 5.1
78
5.1 Technical Parameters
GSM
Power Supply
Telephone Interface FXS (for PBX external line or
phone set)
Interface type 2-wire analog, FXS
GSM module, GSM bandwidth MC55i: EGSM 900/850MHz, GSM 1800/1900MHz
Transmission power
2 W EGSM 850/900 MHz,
1W GSM 1800/1900 MHz
Receiver sensitivity -104 dBm
Audio
HR+FR+EFR Half rate+Full rate+Enhanced full rate
Echo cancellation, Echo suppression
DATA
GPRS Class 10, 4+2 max. 85.6 kbps downlink
CSD max. 14.4 kbps; Coding scheme CS 1, 2, 3, 4
Analog Fax and Data -
models with FAX converter
Fax Group 3, up to 9,6kbps
Data up to 56kbps (Limitation of GSM network - see
6.3)
Antenna
850/900/1800/1900 MHz 50 
SMA antenna connector
SIM card 3/1,8V plug-in
Mains supply 230/12V; 0,5A adapter
DC power supply 10 to 16 V DC (accumulator 12V)
12V consumption
Standby 100 mA
Call/data typ. 300 mA, max. 400 mA
Supply connector DC Jack 5,5/2,1 mm
