8.19 G5-19A, G6-23A
Hydraulic System
8.11.8 Hydraulic Cylinder Torque
Specifications
Description G5-19A G6-23A
All Cylinder Set Screws 15-18 lb-ft (20-25 Nm) 15-18 lb-ft (20-25 Nm)
Lift/Lower Cylinder
Head Gland 369-406 lb-ft (500-550 Nm) 516-553 lb-ft (700-750 Nm)
Piston 1593-1630 lb-ft (2160-2210 Nm) 1940-1977 lb-ft (2630-2680 Nm)
Extend/Retract Cylinder
Head Gland 221-258 lb-ft (300-350 Nm) 221-258 lb-ft (300-350 Nm)
Piston 406-443 lb-ft (550-600 Nm) 406-443 lb-ft (550-600 Nm)
Tilt Cylinder
Head Gland 295-332 lb-ft (400-450 Nm) 516-553 lb-ft (700-750 Nm)
Piston 948-985 lb-ft (1285-1335 Nm) 1940-1977 lb-ft (2630-2680 Nm)
Compensating Cylinder
Head Gland 295-332 lb-ft (400-450 Nm) 295-332 lb-ft (400-450 Nm)
Piston 822-859 lb-ft (1115-1165 Nm) 822-859 lb- ft (115-1165 Nm)
