9.29 G5-19A, G6-23A
Electrical System
JOYSTICK: X POSITION ±XXX% Displays position in percentage for this
axis
X NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether joystick is in neutral
position for this axis
Y POSITION ±XXX% Displays position in percentage for this
axis
Y NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether joystick is in neutral
position for this axis
AR ±XXX% Displays position in percentage for the
analog rocker
AR NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether analog rocker is in
neutral position
S1 ON/OFF Displays status of S1 pushbutton
S2 ON/OFF Displays status of S2 pushbutton
S3 ON/OFF Displays status of S3 pushbutton
S4 ON/OFF Displays status of S4 pushbutton
F1 ON/OFF Displays status of F1 pushbutton
SYSTEM: GM
BATTERY XX.XV Ground module battery voltage
Diagnostics Submenu
(Displayed on Analyzer 1st
Line)
Parameter
(Displayed
on Analyzer
2nd Line)
Parameter Value
(Displayed on Analyzer
2nd Line)
Description
