9.13 G5-19A, G6-23A
Electrical System
9.5 CIRCUIT BREAKDOWNS
9.5.1 Charge Circuit Breakdown
K B A F D E C H J G S O M N L Q R P W U V T X
MAH1180
POSITIVE CABLE
TO BATTERY +
NEGATIVE CABLE
TO BATTERY DISCONNECT
OR BATTERY -
50mm (BLK)
50mm (RED)
ENGINE HARNESS
DEUTSCH HD36-24-23SE
ALL 1.0 MM WIRES IN THIS CONNECTOR
CAB HARNESS
X07
ALTERNATOR
ALT BAT
ALT BAT
16mm (RED)
16mm (RED)
AL
T
W
AL
T
D+
DASH BOARD
X11
AL
T
W
S + -
TACH
AL
T
W
BATTERY
TO IGN SGN B
AL
T
D+
ENGINE HARNESS
ALT W
ALT D+
TO CAB HARNESS
TO DASH BOARD
X11
X07
M
STARTER
32 33 34 35 36 18 3 5 23 15 31 7 8 2 9 11 22 4 17 10 14 13 16 12 1 6 19 20 21 24 25 26 27 28 29 30
