General Information and Specifications
2.6 G5-19A, G6-23A
2.3 SPECIFICATIONS
2.3.1 Travel Speeds
2.3.2 Hydraulic Cylinder Performance Specifications
Note: Machine with no load, engine at full throttle, hydraulic oil above 130° F (54° C) minimum, engine at operating
temperature.
2.3.3 Electrical System
Note: Refer to Section 9.3, “Fuses and Relays,” for more information.
G5-19A G6-23A
First Gear 6 mph (10 kmph) 4 mph (7 kmph)
Second Gear 21 mph (34 kmph) 20 mph (33 kmph)
Function Approximate Times (sec.)
G5-19A G6-23A
Boom Extend 5.66 7.09
Boom Retract 4.51 5.59
Boom Lift 5.87 8.05
Boom Lower 3.79 5.55
Attachment Tilt - UP 2.48 4.30
Attachment Tilt - DOWN 1.97 3.32
Battery:
Type, Rating 12V DC, Negative (-) Ground, Limited Maintenance,
Wet Charged
Quantity 1 (100 Ah) (C
20
)
Reserve Capacity CCA @ -.4° F: 880 EN
Group/Series DIN 600,44
Alternator 14V, 70 Amps
Starter 12V, 3,0 KW Type EV (Gear Reduction)
